Range

660 mm

Setting Range

60 ... 660 mm

Switching Hysteresis

 < 1 %

Light Source

Laser (red)

Wavelength

655 nm

Service Life (T = +25 °C)

100,000 h

Laser Class (EN 60825-1)

1

Max. Ambient Light

10,000 Lux

Light Spot Diameter

see Table 1

Supply Voltage

10 ... 30 V DC

Current Consumption (Ub = 24 V)

< 50 mA

Switching Frequency

100 Hz

Response Time

 < 5 ms

On-/Off-Delay (RS-232)

0 ... 1 s

Temperature Drift

< 50 µm/K

Temperature Range

-25 ... 60 °C

Number of Switching Outputs

2

Switching Output Voltage Drop

< 1.5 V

Switching Output/Switching Current

200 mA

Short Circuit Protection

yes

Reverse Polarity Protection

yes

Teach Mode

HT, VT, FT, TP

Baud Rate

9,600 Bd

Protection Class

III

FDA Accession Number

1120728-000

Setting Method

Teach-In

Housing Material

Plastic, ABS
Plastic, PC

Degree of Protection

IP67

Connection

M12 × 1; 4/5-pin

Optic Cover

Plastic, PMMA

Weight

43 g

MTTFd (EN ISO 13849-1)

918.59 a

Error Output

yes

PNP NO

yes

RS-232 with Adapterbox

yes

External teach-in input

yes

Output

Error Output
Push-pull
NPN
PNP

Circuit

NC
NC/NO
NO

Other parameters

Exposure time
Laser light
Switching hysteresis
Teach-in mode
Off-delay
On-delay
