Measurement method: rectifier process

• Measurement input: alternating voltage sinusoidal, arithmetic mean value measurement, effective value calibration

• Measuring range limits: 0...50 to 0...600 V

• Measurement output: Unipolar and live-zero
  0...1.0 to 0...20 mA resp. live-zero 0.2...1 to 4...20 mA or
  0...1 to 0...10 V resp. live-zero 0.2...1 to 2...10 V

• Also available with power supply via output circuit at 2-wire connection

• Power supply: AC or DC power supply or wide DC, AC power pack tolerance

• Standard as marine version per Lloyds Register of Shipping

• P8/35 housing for top-hat rail mounting

• CSA certificate, German Lloyd approval
